GE-FANUC IC693MDL753LT Output Module
2025-01-09 BY
IN Industry trends

IC693MDL753H|90-30 series positive logic discrete output module

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc; Emerson Automation (Current) Emerson Automation (current)
Series Series 90-30
Part number IC693MDL753
Product description Discrete output module
Product description Discrete output module
Product Type Digital I/O
Number of channels 32 (32)
Nooooo. Number of output groups four (4)
Compatibility GE Fanuc 90-30 Programmable controllers
Nooooo. Group number four (4)
Number of channels per group 8 (8)
GE-FANUC IC693MDL753LT Output Module

The IC693MDL753 is a digital output module of the 90-30 series Programmable Logic Controller (PLC) series. The module has thirty-two (32) positive logic output channels that produce an output voltage range of 102-28.8 with a nominal voltage of 12-24 VDC. The IC693MDL753 was previously manufactured by GE Fanuc Automation and has now been acquired by Emerson Automation. The module specifically comes with output groupings, four (4) groups of eight (8) outputs each. Each output group has 250 V and 100 V isolation or optical isolation between the field side and the logical side. The IC693MDL753 has an output current rating of 0.5 amps per point, with a maximum of 4 amps per group and 3 amps per group of common pins. It produces a surge current of 5.4 amps for 10 ms, while the on-voltage drops to 0.3 VDC. The Off state leakage current is 0.1 mA, while the On and Off response times, typical for both signal transitions, are 0.5 ms. The IC693MDL753 has an internal power consumption of 260 mA from the 5-VDC backplane. The IC693MDL753 is compatible as both local and distributed I/O modules. It can be installed in any available slot in the chassis, except for specified CPU, communication adapter, and dedicated module slots. The IC693MDL753 occupies one slot and can be installed as many times as needed, limited by the host controller’s I/O capacity and memory. To connect electrical loads to this discrete output module, the IC693CBL315 recommended manufacturer’s cable assembly.

The IC693MDL753 I/O module is a 32-point digital I/O module. The IC693MDL753 I/O module was developed by GE Fanuc for the 90-30 series of GE programmable logic controllers or PLCS. When using the 5-volt DC voltage supplied by the PLC backplane, the module has a peak current consumption rating of 260 mA. When each output point is ON, it consumes 16 mA of current, and the LED indicator at each output point consumes 4.7 mA of current. The 32 points were divided into 4 groups with 8 outputs per group. When operating at 24 volts DC, each set of points consumes 16.5 milliamps of current when all eight outputs in the group are ON. When operating at 12 volts DC, each group consumes 9.6 mah of current when all eight outputs in the group are on. The inrush current of the IC693MDL753 I/O module is 5.4 amps. Both the on-response time and off-response time have a maximum value of 0.5 ms. The maximum output current of each point is 0.5 amps, and the maximum output current of each group is 4 amps. The output voltage range of the IC693MDL753 I/O module is 10.2 to 28.8 volts DC. The output on the module is positive logic output. The output switches the load of the positive terminal of the power supply and provides current to the load. Each set of output points can be used for different loads. The optocoupler provides isolation between the logical side and the field side of the IC693MDL753 I/O module. When the PLC’s CPU stops, all module outputs are forced into the OFF state. The output circuit is connected via two 24-pin male connectors on the front of the module.

GE IC693MDL730: Advanced Output Module for Industrial Control Systems
2025-01-09 BY
IN Industry trends

IC693MDL730|12/24 VDC positive logic output module

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc
Part number IC693MDL730
Series Series 90-30
The life cycle status is positive
Part number IC693MDL730
Power Supply Type DC
Product description Discrete output module
Output power voltage 12 to 24 VDC
Number of channels eight (8), single group
GE IC693MDL730: Advanced Output Module for Industrial Control Systems

The IC693MDL730 is a positive logic output module in the GE Fanuc 90-30 series Programmable Logic controller (PLC) product family, now part of Emerson Automation. The module has eight (8) discrete output channels in a single set, providing an output voltage range of 12-24 VDC with a ripple of +20%, -15%. Each channel provides an output current of 2 amps per point; 60 amps per fuse at 2 ° C; 50 amps per fuse at 4 degrees Celsius. The IC693MDL730 has a 1500 V isolation between the magnetic field side and the logical side. The output channel has a surge current rating of 9.4 amps for 10 milliseconds; The maximum output voltage drop is 12 volts; The maximum off state leakage current is 1 mA, and the typical on and off response time for each transition is 2ms. The module occupies a single slot on a 90-30 backplane and is compatible with any I/O slot on a 90-30 series five (5) or ten (10) backplane. When all outputs are energized, its current consumption is 55 mA, coming from the 5 VDC bus on the backplane. The IC693MDL730 is compatible with a wide range of electrical loads, especially motor starters, solenids and indicators. An external power supply must be connected to the module to provide operating power. The status LED indicator is installed on the front panel of the module and includes a fuse indicator, a module failure indicator, and eight (8) channel indicators assigned to each output channel that describe the operating status of each output point. The module comes with a removable terminal board to simplify maintenance.

The IC693MDL730 PLC module has a 12 to 24 volt DC voltage rating with positive logic and 2 amp output current. The component has a DC power supply and comes with 8 points. The device has a load current of 2 amps per point, while response times are rated at 2 ms ON and 2 ms OFF. The output type is transistor output, and the module has positive polarity. The connector type is the terminal box with 20 screws that comes with the module.

GE FANUC IC693DNM200 - DeviceNet Master Module for Industrial Automation
2025-01-09 BY
IN Industry trends

IC693DNM200|A single slot DeviceNet master module

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc
Part number IC693DNM200
Product Description DeviceNet master station module
Compatibility 90-30 series, PACSystems RX3i
Communication port one (1) DeviceNet terminal; One (1) service port
Supported network DeviceNet device network
Communication speed 125K, 250K and 500K
Data rates of 125K, 250K and 500K baud are supported
Module Position Any slot in Series 90-30 other than slots 0 and 1
Rated voltage 12 to 24 volts DC, positive logic
GE FANUC IC693DNM200 - DeviceNet Master Module for Industrial Automation

IC693DNM200 is the DeviceNet master module. The module is a single-slot communication module that is part of the 90-30 series Programmable Logic Controller (PLC) platform formerly manufactured by GE Fanuc and now owned by Emerson Automation. The module is equipped with a DeviceNet terminal. It also has one (1) RS232 9-pin D-case female port used as a module service port. The IC693DNM200 supports all data rates of the DeviceNet protocol, especially 125K, 250K and 500K transfer rates. Each slave master can transmit up to 255 bytes of input data and 255 bytes of output data, and up to 3972 bytes of input data and 3972 bytes of output data can be transmitted to this master module. In addition, a total of 126 I/O connections can be established using this module, as it is able to communicate with up to 63 slave devices, each of which can be assigned a maximum of two (2) I/O stations. The module supports and configurable data connections that are polling, stroboscopic, cyclic or COS. The DeviceNet master module also supports explicit messaging, unconnected message Manager (UCMM), and one (1) proxy connections per slave cell. In addition, the module can be run in dual mode, as both Master and Slave. Failure behavior can be configured, especially during communication loss, to provide an acceptable system response in the event of said errors. This module also comes with upgradeable firmware that allows module updates and bug fixes to be downloaded via the RS232 service port.

The IC693DNM200 module is a DeviceNet master station module designed and manufactured by GE Fanuc. The device is part of the 90-30 series and has various integrated functions for messaging and data transfer applications. Most of these functions are automatic, and the device works on a DeviceNet network that includes other devices and hosts. The IC693DNM200 module can be installed on the host of the 90-30 series or PACSystems RX3i systems, but is not suitable for remote or extended racks. The IC693DNM200 DeviceNet module has 32 output points and supports standard data rates of 125K, 250K and 500K baud. The outputs are arranged in groups of 4, each covering 8 points. The unit is rated at 12 to 24 volts DC (positive logic), and its backplane consumes 450 mA at 5 volts DC. The GE Series 90-30 DeviceNet IC693DNM200 module has an output current of 0.5 amps per point and a surge current of 5.4 amps for a duration of 10 milliseconds. For output currents, it should be noted that the limit output current for each group is 4 amps, while the output current for each group of common pins does not exceed 3 amps. In addition, the on-state voltage drop is 0.3 volts DC, while the on/off response time does not exceed 0.5 ms. The IC693DNM200 module is very reliable and can operate in a temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). In addition to this, the device has a specified storage temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit).

GE FANUC IC693CPU374 - TCP/IP Ethernet Communications Module
2025-01-09 BY
IN Industry trends

IC693CPU374|The typical sweep rate for Boolean contacts is 0.15 milliseconds per 1K logic

Brand GE Fanuc
Series Series 90-30
Part number IC693CPU374
I/O count 2048
Processor speed 133 megahertz
Register memory 240 KB
The power supply requires 7.4 watts at 5 volts DC
Floating point math, yes.
Processor Model Embedded 586
Serial port RS-485 (via power supply)
Ethernet port number 2
Operating temperature 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
GE FANUC IC693CPU374 - TCP/IP Ethernet Communications Module

The IC693CPU374 is a GE Fanuc Programmable Logic controller (PLC) module in the 90-30 series. The module is a processor module for hosting user programs, executing logic, and data exchange managed with the processor through an embedded communication port.

IC693CPU374 can also be called controller. The controller has a built-in microprocessor with an embedded 586 processor and a processing speed of 133 MHz. Its typical scan rate is 0.15 ms per 1K Boolean contact logic. This controller module has a single slot width mounted on a 90-30 PLC rack.

The user memory of IC693CPU374 is 240KB. It has two (2) Ethernet communication ports, supports 10/100 Mbps transmission speed, and has automatic sensing function. These ports enable the controller to connect to an Ethernet network in order to communicate with programming workstations such as desktops or laptops, with human machine interface (HMI) and supervisory control and data acquisition (SCADA) systems, and with other processors used for messaging functions. The controller can also communicate via the RS485 communication interface on the power supply, whether it is a standard power supply or a high capacity power supply.

The controller accepts user programs developed using a variety of programming software applications, Examples include VersaPro version 2.03 or later, CIMPLICITY Machine Edition Logic Developer version 2.60 or later, and control software version 2.50 or later. When making online edits to the controller using an existing user program, use the same or later version of the same software.

The IC693CPU374 CPU has a processor speed of 133 megahertz and a total user memory of 240 KB. Program memory can be configured according to application requirements, and it includes a register memory that can be configured in the range of 128 to 32,640 words, and a configurable memory for analog input and analog output. The memory of the system register supports up to 28 words, and users can set about 2000 timers and counters. The IC693CPU374 CPU uses an AMD SC80386 type 520EX processor and has 2 built-in Ethernet ports that allow 10/100 base-T/TX communication. Featured Ethernet ports are connected through RJ-45 connectors. The device also supports an RS-485 port on the power supply and allows communication via SNP and SNPX protocols. In addition, the device also supports a variety of commonly used program storage devices.

GE IC693CPU372-AE D20ME-VME VME Card Module PLC System
2025-01-09 BY
IN Industry trends

IC693CPU372|Supports 2048 discrete inputs

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc
Part number IC693CPU372
Product Description Single-socket CPU with Ethernet interface
Compatible with VersaMax PLC, PAC system, 90 series
User memory 120 KB
Supported communication protocols TCP/IP
Processor type AMD SC520
I/O count 2048
Typical scan rate is 0.15 ms per 1K Boolean logic
GE IC693CPU372-AE D20ME-VME VME Card Module PLC System

IC693CPU372 is a TCP I/P Ethernet communication interface. The module is mainly used to implement Ethernet communication and supports system protocols such as Modbus TCP server/client and industrial Ethernet. The module can be used to perform regular data exchange using Ethernet Global Data (EGD), SRTP, and SRTP clients. The IC693CPU372 supports full PLC programming and configuration services. It comes with dual Ethernet ports, shares the same IP address, and serves as an internal Ethernet switch, allowing daisy-chain connectivity for networking and device-level loop (DLR) topology. Each port supports network automatic sensing, eliminating the need to assign modules to existing network speeds. The IC693CPU372 comes with a dedicated processor with a clock speed of 133 MHz. For configuration, the built-in Web server allows remote connection to configuration stations and can be used to introduce simple configuration for modules as well as module monitoring. For programming programmable Logic controller (PLC) functions, the IC693CPU372 is configured using the Machine Edition of PLC Logic Developer in the Proficy Machine Edition package. IC693CPU372 Support It supports 2048 discrete inputs, 2048 discrete outputs, 128-32,640 analog input words, and 128-32,640 analog output words (Max.) for a total user memory of 240 KB. This built-in memory is a random access memory (RAM) type and is backed up by a battery. Optional non-volatile memory or flash memory can be added to provide memory that does not require battery power to retain the contents of the memory.

The IC693CPU372 module is designed and manufactured by GE Fanuc. The industrial communication module is designed to communicate over industrial Ethernet operating over the TCP/IP protocol. The unit is compatible with GE PLC equipment provided in the 90-30 series or VersaMax series or PLC equipment as part of PACSystems. The IC693CPU372 module has an integrated interface for Ethernet communication and can be used with hosts that have all the necessary software tools installed. The Ethernet interface supports up to 3 different 90-30 series modules that can provide additional functionality. The backplane of the 90-30 series programmable logic controllers can use combination modules to improve the performance of the entire system. The IC693CPU372 communication module has 2048 input/output points and a memory capacity of 240 KB. Like most similar components in the series, the module has a type 80386EX processor and is intended for use in 32-bit systems. The device supports communication over popular networks such as 100BaseTX, IEEE 802.3, and 10BaseT networks. For this purpose, the device includes two shielded Ethernet ports with automatic sensing functions. The unit has a pair of Ethernet connectors, a Station Manager functional connector, LED status indicators, a master switch, and a restart button. The IC693CPU372 module supports floating point math, duplex mode, simple configuration and programming, and SRTP server options. The IC693CPU372 module’s processor operates at 133 MHZ and supports RAM or flash memory for storage. The unit is powered by a backup battery and requires 5 watts at 7.4 volts direct current.

GE Fanuc IC693CPU351 - PAC Systems RX3i Control Module
2025-01-09 BY
IN Industry trends

IC693CPU351-HT|Single-slot modular CPU

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc
Part number IC693CPU351
Product Description Modular CPU
Product Type CPU module
User memory 240 KB
Compatibility GE Fanuc 90-30 Programmable controllers
Processor type 80386EX
Clock speed 25 megahertz
Typical scan rate is 0.22 ms per 1K Boolean logic
Serial port 3
The processor speed is 25 MHZ
GE Fanuc IC693CPU351 - PAC Systems RX3i Control Module

The GE Fanuc 90-30 module with directory number IC693CPU351 is part of the modular CPU subclass. The CPU is designed for applications that require higher complexity, faster processing speed, and support for large amounts of I/O. The CPU module is a single-slot CPU module that can be mounted to CPU baseboards in slots 5 or 10. The IC693CPU351 specifically supports a large number of I/ OS, 2048 discrete input points (%I); 2048 discrete output points (%Q) and analog I/O words, varying depending on the software used, however, each has a maximum configurable analog I/O of 32, 640 words. The number of other internal registers available for this CPU is 1280 bits of binary global memory; 4096-bit storage coil; 256-bit temporary output coil; 128-bit system state reference; Register memory of up to 32,640 words and system registers of 28,000 words can only be used for reference table viewing. The modular CPU can be configured to communicate and perform I/O data exchange between I/O expansions or remote I/O backboards. Specifically, seven (7) and/or I/O expansion or remote I.O baseboards. For communication with visualization systems such as Human Machine Interface (HMI) or Supervisory Control and Data Acquisition systems (SCADA) and other automation devices, the IC693CPU351 provides three (3) serial ports. One (1) serial port is located on a power connector that supports SNP/SNPX slave stations, while ports 1 and 2 support RTU slave stations and SNP/SNPX master/slave protocols. The modular CPU also supports the installation of communication modules.

The GE Fanuc IC693CPU351 CPU is a modular CPU module. The IC693CPU351 CPU was developed for the 90-30 series Programmable Logic controller (PLC) system. The CPU has a clock speed of 25 megahertz. The processor type is 80386EX processor. The IC693CPU351 CPU is part of the GE350 to 364 CPU family, which was developed specifically to meet customer needs for faster processing speeds and increased memory size. The IC693CPU351 CPU is supported by Logicmaster microprogramming and configuration software versions 90-30, 6.0 and higher, and control programming and configuration software versions 2.0 and higher. The user memory on the IC693CPU351 CPU is 240 KB (supported by CPU firmware 9.0 and later). For firmware before version 9.0, the CPU module memory size is 80 KB. The IC693CPU351 CPU does not support an embedded Ethernet port, but there are three built-in serial ports on the CPU module. Optional communication modules available for the IC693CPU351 CPU include Profibus, GBC, Ethernet, GCM, and GCM+ modules. The IC693CPU351 CPU supports floating point math functions. The IC693CPU351 CPU also provides a key switch. A sequential event logger is also provided on this module. The internal coil on the module is rated at 4096 bits and the output (temporary) coil is rated at 256 bits. The power supply of the IC693CPU351 CPU is required to be 5 volts DC and 890 mA. Battery powered clock and override are available on the IC693CPU351 CPU. Operating temperature range is 32 to 140 degrees Fahrenheit.

GE FANUC IC693CPU350-EK: Advanced Programmable Logic Controller Module
2025-01-09 BY
IN Industry trends

IC693CPU350-BC|Has a single slot width

Brand GE Fanuc
Series Series 90-30
Part number IC693CPU350
Operating temperature 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
Serial port RS-485 (via power supply)
CPU Type Single-socket CPU module
User memory 32K bytes
Processor type 80386EX
The power supply requires 670 MA from a +5 VDC power supply
Typical scan rate 0.22 ms per 1K logic (Boolean contacts)
Memory Storage types RAM and flash
The number of Ethernet ports is not applicable
Storage temperature -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
GE FANUC IC693CPU350-EK: Advanced Programmable Logic Controller Module

The IC693CPU350 is a GE Fanuc series 90-30 controller. The controller is part of a modular control system with a single slot-wide module capable of controlling up to eight (8) backboards, including the local backboard where the CPU is installed.

The IC693CPU350 is designed with 32K bytes of non-configurable user memory. Up to 2048 discrete inputs, 2048 discrete outputs, 2048 analog input words and 512 analog output words. This I/O count density makes the controller eligible for installation in medium to large sized applications.

The IC693CPU350 does not have a communication port. The controller utilizes a communication port installed in the power supply, which is an RS485 communication interface that allows connection to programming workstations, handheld programmers (HHP), and devices capable of exchanging data over the RS485 communication standard. This port supports the SNP/SNP-X slave protocol.

The IC693CPU350 is configured with various options. It can be configured using LogicMaster90, Control, VersaPro, and CIMPLICITY Machine Edition Logic Developer applications. In addition, a traditional handheld programmer (HHP) can be used to write programs to this controller.

The IC693CPU350 has an internal processor, 80386EX, with a typical sweep rate of 0.22 milliseconds per 1K logic for Boolean contacts and a processing speed of 25 MHz. The controller supports override functionality, interrupts via periodic subroutines, PCM/CCM compatibility, and floating-point math. Additional communication modules supported by IC693CPU350 Optional communication protocols after installation include Ethernet, FIP, Profibus, GBC, GCM, GCM+ option modules.

The IC693CPU350 CPU is a single-slot CPU module. Each system has eight backboards, including CPU backboards and seven extension or remote backboards. The IC693CPU350 CPU requires 670 mah of current and 5 volts of DC input. The typical scan rate for CPU modules is 0.22 milliseconds per 1 KB of logic. The maximum user program memory is 32 KB. The capacity of the discrete input point is 2048 words, and the capacity of the discrete output point is 2048 words. The discrete global memory is 1280 bits. Register memory is 9999 words. Analog inputs and outputs are rated at 2048 words and 512 words, respectively. The system register is 28 words. The IC693CPU350 CPU supports more than 2000 timers and counters. The CPU module also supports Shift registers. The IC693CPU350 CPU has an integrated serial port that supports SNP/SNPX slave protocols. The serial port requires a PCM module to support the RTU master, and a CMM module to support the SNP/SNP-X master, RTU slave protocol, or CCM. Both flash and RAM memory can be used in the IC693CPU350 CPU. The IC693CPU350 CPU also supports floating point math. The operating temperature range of the IC693CPU350 CPU is 0 to 60 degrees Celsius.

GE FANUC IC693CMM302L - Advanced Communication Module for Industrial Automation
2025-01-09 BY
IN Industry trends

IC693CMM302|The module supports data exchange for up to 31 devices

Manufacturer GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc/Emerson Automation
Part number IC693CMM302
Series Series 90-30
Product Type Enhanced Genius communication module
Product Description Genius Communication module
Number of supported bus devices 31
Slot width Single slot
Compatible host equipment GE series 90-30 PLC
Slot Allocate any slot except the CPU slot
Compatible backboard CPU, extension and remote backboard
Installation position 90-30 series baseplate
LED 2 (OK LED and COM LED)
GE FANUC IC693CMM302L - Advanced Communication Module for Industrial Automation
The IC693CMM302 is a Genius communication module in Emerson Automation’s Series 90-30 Programmable Logic controller (PLC) family, formerly known as GE Fanuc Automation. The module is a single slot width module that provides Genius protocol connectivity, and each controller can communicate with up to 31 devices and 62 devices, as the 90-30 series system allows up to two (2) IC693CMM302s per controller to be configured. The IC693CMM302 Each IC693CMM302 allows transmitting 128 bytes and receiving 128 bytes of global data, and supports PLC registers. Examples include global register (%G), discrete input (%I), discrete output (%Q), analog input (%AI), analog output (%AQ), and register memory (%R). It supports software-based diagnostics such as status bits, 90-70 PLC series fault reporting. The module’s environmental rating includes operating temperatures from 0 oC to +60 oC (+32 oF to +140 oF); The storage temperature is -25 oC to +70 oC (-13 oF to +158 oF); Humidity ranges from 5% to 95% (non-condensing), while mechanical ratings include 0.2 inch displacement, operating vibration from 5 Hz to 10Hz and 1 G, 10Hz to 200 Hz, and operating shock from 5 G to 10 ms duration. In addition to global data exchange, the IC693CMM302 allows for data monitoring via personal or industrial computers, monitoring data using I/O blocks, device communication via the Genius bus, and I/O simulation. The IC693CMM302 has a backplane power consumption of <300 mA at 5VDC. In addition to the 90-30 series PLCS, it can also be used with the 90-70 Series, the six-series PLCS, and the Genius Handheld Display (HHM) for local configuration.

The 90-30 Series IC693CMM302 communication module was designed and manufactured by GE Fanuc as a GCM+ device, also known as the Enhanced Genius communication module. The IC693CMM302 enhanced Genius communication module can communicate with global data between up to 32 devices. These devices are GE series 90-30 PLCS and 31 other devices connected to the Genius bus. The IC693CMM302 Enhanced Genius communication module is recommended to be installed on the CPU backboard of the host PLC system for the most efficient operation, but it can also be installed on a remote backboard or an extended backboard of the same system. However, the enhanced Genius communication module cannot be installed in a PLC with a regular Genius communication module or GCM. Multiple enhanced Genius communication modules, such as the IC693CMM302 module, can be installed in a single PLC system, and each Enhanced Genius communication module has its own Genius bus, which means that each module can connect to and communicate with up to 31 additional devices simultaneously. For example, the 90-30 series GE PLC with 2 enhanced Genius communication modules can communicate with up to 62 other devices simultaneously. The IC693CMM302 enhanced Genius communication module is primarily used to exchange global data, but it can also handle data monitoring for industrial or personal computers, point-to-point and master-slave communication between bus devices, and data monitoring from Genius I/O blocks (note that the communication module has no control over these I/O blocks).

General Electric IC693CHS397 Control Module - Advanced Automation Solutions
2025-01-09 BY
IN Industry trends

IC693CHS397|5-slot baseplate for the 90-30 series Programmable Logic Controller (PLC) platform

Manufacturer GE Fanuc
Series Series 90-30
Nooooo. Number of CPU slots 1 (1)
Manufacturer GE Fanuc (ex); Emerson Automation (Current) Emerson Automation (current)
Part number IC693CHS397
Nooooo. Number of power sockets 1 (1)
Series Series 90-30
Product Type CPU mainboard
Slot allocation CPU/ Dedicated module: Slot 1 I/O module/Optional module: Slot 2-5 Unnumbered slot: Power module Expansion cable: expansion cable
Product Description 5-socket CPU mainboard
General Electric IC693CHS397 Control Module - Advanced Automation Solutions

The IC693CHS397 is a 5-slot baseboard for the 90-30 series Programmable Logic controller (PLC) series. The hardware was part of GE Fanuc Automation during the active life of the product family, but the PLC family and other products were recently acquired by Emerson Automation. The IC693CHS397 has a total of five (5) slots and another uncounted slot dedicated to the power module. The backboard has one (1) slot dedicated to a central processing unit (CPU) or dedicated module, four (4) slots allocated to I/O, and option modules. It also provides an expansion slot located on the far right of the hardware for rack expansion. Only one (1) CPU is allowed to be installed on this backboard. In addition, the same slot of the CPU (Slot 1) is also compatible with communication modules such as FIP remote I/O scanners and similar modules. Slot 2 and other I/O slots have a unique size and do not fit into any other module. This provides connection security and prevents damage to other modules during installation. The mainboard expansion port provided is a 25-pin D-shaped housing female connector that is installed on the far right side of the hardware. When connecting expansion cables or implementing multiple expansion plates, ensure that the total length of the cables does not exceed 50 feet or 15 meters. The IC693CHS397 is designed for panel mounting via the provided mounting strip. The hardware measures 10.43 x 5.12 x 5.59 inches. (W x H x D), the internal power consumption is 270 mA at 5 VDC.

GE Fanuc IC693CHS397 5-slot baseplate of the GE Fanuc Series 90-30 for hosting modular cpus or cpus, I/O, and dedicated modules. The IC693CHS397 baseboard has five slots for mounting various cpus and other devices that make up a complete PLC or programmable logic controller. Technically, the GE Fanuc IC693CHS397 baseboard has a total of six slots, not just five, but the first slot on the left side is not numbered as it is always and only used to host the PSU. The size and shape of this power socket is different from the numbered five slots, and its size and shape can only accommodate one power supply and not any other power supply. GE Fanuc Series 90-30 IC693CHS397 5-slot CPU The five main slots in the baseboard consist of one CPU slot (the name of the baseboard) and four non-CPU slots that can host the I/O module. The IC693CHS397 also has an I/O expansion bus connector on the far right edge of the backboard, which can be used to extend the I/O communication capability of the backboard beyond what four I/O slots can handle. The expansion and remote backboards can be connected to the IC693CHS397 CPU backboards as part of a large PLC system, but there can only be one CPU backboard in the PLC. The CPU baseboard is always installed in Rack 0 of the PLC system. Since the IC693CHS397 CPU baseboard supports modular cpus, it is easy to replace or upgrade the CPU module if necessary.

GE IC693CHS391N - CPU Module Base with 10 Slots, for Advanced Industrial Control Systems
2025-01-09 BY
IN Industry trends

IC693CHS391|10-slot modular CPU backboard

Brand GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc
Part number IC693CHS391
Series Series 90-30
Description expansion backboard
Product Description Modular CPU mainboard
Currently 420 mah

IC693CHS391 is a modular CPU mainboard. The baseplate is part of the 90-30 series manufactured by GE Fanuc. The device includes connection ports that allow the installation of modular cpus, I/O modules, and power modules. It has a total of ten (10) slots, of which one (1) slot is allocated to the CPU and nine (9) slots are allocated to the I/O module. Power sockets are not included in the slot count, nor are bus expansion ports. Since this is a modular CPU slot, by default it is assigned a node address of 0, which can be modified by programming software. The system supports only one (1) modular CPU slot. Other slots in the system can be expansion or remote I/O backboards. The power supply is installed in the leftmost slot, which is not included in the slot count, allowing this baseboard to support more I/O. The CPU is only installed on slot 1 because the slot is especially sized for CPU connections or special option modules, such as FIP bus remote I/O scanners. Slots 2 and higher are particularly suitable for I/O or option modules. The extension or remote I/O baseboard connects to the extension port on the far right of the baseboard. The IC693CHS391 modular CPU backboards support up to four (4) or seven (7) expansion backboards, depending on the CPU hosted by the IC693CHS391. This base plate supports panel mounting only and is secured by screws and washers through the provided mounting holes.
GE IC693CHS391N - CPU Module Base with 10 Slots, for Advanced Industrial Control Systems

The IC693CHS391 baseboard is an expansion baseboard manufactured by GE Fanuc with 10 slots. It has a rated current of 420 mA and a rated voltage of 5 volts DC. It is equipped with a DIP switch. The expansion backboard is connected to the 90-30 series PLC along with other modules. The power module is inserted into the left slot of the mainboard. The IC693CHS391 baseplate is modular in size and has an open housing. If additional features are needed, it can be easily installed and replaced or changed to a different type. The left side of the board has a power port, as well as connection slots for CPU and non-CPU slots. It also has a 25-pin female connector on the right side for connecting expansion and remote baseboards. To connect to the remote baseboard, the IC693CHS391 expansion baseboard requires a cable less than 700 feet in length. The backplane cannot be used as a single primitive. It can be connected to a PLC device or a personal computer using a PCI card. It can be connected to up to 7 cpus at a time, depending on the CPU model used. The IC693CHS391 backboard can be mounted vertically or horizontally, depending on the layout of the PLC or CPU. The ambient temperature should always be within the specified range. Dishes should be kept away from water splashes and sources of dust, dirt and harmful chemicals. The IC693CHS391 baseplate is certified to several global environmental and industry standards.
